Gold Electrolytic Refining Machine strips the gold layer from the surface of electronic components, thereby obtaining crude gold with a purity level that can range from 70% to as high as 97% to 99%. This crude gold, after being processed and refined further using a gold refining machine, can achieve extremely high purities of 99.9%, 99.99%, 99.999%, 99.9999%, or even higher.
Gold Refining Methods
Gold refining primarily employs three techniques:
1.Chemical Reduction: Ideal for small-scale refining of crude gold.
2. Solvent Extraction: A versatile method for separating and purifying gold.
3. Electrolytic Refining: Optimized for large-scale purification of crude gold from diverse sources into high-purity gold (99.99%).
The electrolytic refining method ensures superior efficiency and scalability, making it the preferred choice for industrial-grade gold production.
Gold Electrolytic Refining Process Flow
1. Electrolyte Preparation
The chlorination dissolution method is employed to dissolve gold. The dissolved gold solution is diluted with a hydrochloric acid aqueous solution to a specific concentration to form the electrolyte.
2. Crude Gold Ingot Casting
Crude gold (with purity ≥95%) and secondary-reduced gold powder are melted in a medium-frequency furnace, then poured into specialized anode molds to cast gold anode plates.
3. Electrolytic Refining
Transfer the prepared electrolyte into electrolytic cells. Suspend the gold anode plates at designated positions in the cells. Initiate electrolysis using a combined AC/DC power supply system to enable more thorough refining.
4. Cathode Gold Processing
After completing electrolysis, deactivate the power supply. Extract the cathodes, detach and clean the deposited gold from them. The purified gold is then dried, cast into ingots, labeled, and stored in inventory.
5. Exhaust Gas Treatment System
Spent electrolyte and waste gases generated during electrolysis are directed into the exhaust treatment system. After processing, emissions become colorless and odorless before release.
6. Wastewater Treatment System
Gold powder rinse water and post-treatment waste liquids containing heavy metals (with trace gold residues) undergo neutralization for heavy metal removal. Activated carbon adsorption is then applied to recover residual gold, ensuring discharged wastewater contains no precious metals.
Raw Material&Final Product
Rough Gold
Crude Gold
Coarse Gold
Cathode gold
Refined Gold
Gold Refined
Au99.9999%
Finish Gold
Equipment Advantages
1. Simple Operation & High Purity
The system features straightforward operation and delivers high-purity gold. It can also produce 99.9999% purity gold ingots upon special request.
2. PLC Remote Control & Data Monitoring
Equipped with a PLC-based remote control system and real-time data monitoring capabilities for precise process management.
3. Eco-Friendly Design
The system is environmentally friendly and pollution-free. Exhaust gases are treated via the gas treatment system to ensure colorless, odorless emissions. Wastewater is processed to guarantee the absence of precious metals before discharge.
4. Customizable Capacities
Guanma Machinery, a gold refining equipment manufacturer, provides machines in various capacities, with options for customized configurations to meet client-specific requirements.
5. Flue Gas Condensation Unit
To address the high-temperature demands of gold electrolysis, a flue gas condensation device is integrated to condense and reflux volatilized electrolyte, effectively preventing gold loss.
Supporting Equipment
Gold Melting Machine(Metal Melting Furnace)
Features of the Metal Melting Furnace: Suitable for melting various metals, particularly precious metals such as gold, silver, copper, and platinum. The equipment is available in multiple specifications to accommodate different melting capacities. Melting processes are completed within minutes. Compact and lightweight design, equipped with casters for easy mobility. Incorporates an electromagnetic stirring function, eliminating the need for manual stirring with rods.
Vacuum Continuous Casting Machine
Features of the Vacuum Continuous Casting Machine: Temperature max.1500C above; Cast strip, plate, tube, multiple strips, customized; Good color, high density, no porosity, no oxidation; Electromagnetic stirring function, no color segregation.
Vacuum Granulator Machine
Features of vacuum granulator machine: mechanical stirring function to make the product more uniform; secondary feeding can be performed under vacuum to ensure that the metal is fully melted; equipped with a water-locking device to isolate excess moisture and make it easier to take out materials.
Vacuum Ingot Casting Machine
Features of vacuum ingot casting machine: can customize gold beans, gold bars, gold nuggets of different shapes and weights; applicable to precious metals such as gold/K gold/silver; PLC control system, easy operation and smart screen; vacuum ingot casting.
Technical Parameter
Gold Electrolytic Refining Machine Technical Parameters
Guanma Machinery Gold Electrolytic Refining Equipment Manufacturer can meet the gold production of 3~50kg per day, and can also be customized according to customer requirements.
| Model | Capacity kg/day | Electrolyte Volume | Size(Length*Width*Height) |
| GER-3 | 1-3kg/day | 7L | about 1800*900*1900mm |
| GER-5 | 3-5kg/day | 12L | about 1800*900*1900mm |
| GER-10 | 10kg/day | 24L | about 1800*900*1900mm |
| GER-15 | 15kg/day | 36L | about 2200*950*1900mm |
| GER-30 | 30kg/day | 56L | about 2200*950*1900mm |
| GER-50 | 50kg/day | 96L | about 2200*950*1900mm |
| The above data is for reference only, the specific configuration is subject to the quotation. | |||
Our Services
Production Flow Diagram
Complimentary provision of production flow diagrams and installation foundation drawings for buyer-required equipment.
Site Layout
Free adjustment services for layout plans during the entire operational process, provided upon buyer request.
Installation Training
During installation and trial operation, our engineers will be dispatched on-site for equipment installation, commissioning, and necessary operational training.
Sample Testing
According to the customer's raw materials, test and send the final sample product. come out testing report to help clients analyze the project.
Accessories Supply
A list of wear-prone and consumable parts is provided. Spare parts are sold at factory prices when purchased directly from Guanma Machinery.
Technical Upgrade Support
Technical updates for equipment are available throughout the production cycle. If clients request upgrades, only material costs will be charged.
